Your products's number
| Chassis | Chassis brand | / | ISUZU FTR |
| Model | / | QL1160 | |
| Drive type | / | 4x2 left hand drive | |
| Cabin | / | double cabin,two row,5 seats | |
| Overall dimension(L*W*H) | mm | 8430x2500x3660 | |
| Total mass | kg | 14950 | |
| Rated Loading capacity | kg | 6100 | |
| Wheel Base | mm | 4700 | |
| Front /rear suspension | mm | 1335/2265 | |
| Approach/departure angle | (°) | 44546 | |
| Spring No. | / | 7/7+5 | |
| Tyre No. | pcs | 6, (front 2, rear 4) | |
| Type & Size of Tyre | / | 10.00-20 | |
| Axle No. | / | 2 | |
| Steering wheel | / | left hand drive | |
| Gear box | / | 5 speed forward with 1 reverse, manual | |
| Engine | Engine model | / | 4HK1-TCG50 |
| Engine brand | / | ISUZU | |
| Engine type | / | 4 cylinders in line | |
| Maximum power | HP/kw | 205/151 | |
| Fuel type | / | diesel | |
| Displacement | ml | 5193 | |
| Max torque | N.m | / | |
| Rated rotor speed | Rpm | / | |
| Emission Standard | / | Euro V | |
| 5,000 litres water tank & 2000 litres foam tank | |||
| Fire pump | Model | / | CB10/40,Normal pressure pump |
| Pressure | Mpa | ≥1.0 | |
| Max suction height | m | 7 | |
| Flux | L/S | 60 | |
| Rated speed | r/min | 3000 | |
| Time of drawing water (s) | s | ≤35 | |
| Input diameter | mm | 125 | |
| Outlet diameter | mm | 2xΦ75 | |
| Fire monitor | Model | / | PL32 |
| Fire fighting nozzle range | Water (m) | ≥60 | |
| Foam (m) | ≥55 | ||
| Flux | L/S | 48 | |
| Rated Working pressure | Mpa | 1 | |
| Rotation angle | (°) | 360 | |
